Design and planning
The design work that decides whether it works.
Most nurse call problems are set before installation begins: in zoning, call routing, cable strategy and the interfaces nobody owned. This is the stage where they get resolved.
Where it fits
- New-build healthcare projects
- Live-ward refurbishment and phased migration
- Estate-wide standardisation across multiple sites
Designed against
HTM 08-03 · BS EN 50173-1 structured cabling
Design and planning
Our scope
What we do on these systems.
- 01Room data sheets and device schedules, with call points confirmed against room use rather than a repeated template
- 02Cable strategy for phased work: what existing two-wire nurse call cable can be retained, and where IP is run
- 03Zoning, call group and escalation design agreed with the ward before it is built
- 04Interface schedule naming every boundary with fire, security, medical devices, DECT and paging, and who owns each
- 05Specification and tender documentation support, including drawings and typical specification text
- 06Acceptance test plans, commissioning records, O&M documentation and a system logbook at handover
Platform
What the system does.
EZ DESIGN is manufactured by Schrack Seconet. Product names and specifications are theirs.
- Manufacturer planning tools, connection diagrams and typical specification text
- BIM objects and AutoCAD libraries for coordination with the wider design team
- Mixed legacy-bus and IP topologies planned in one system, so migration can be phased
- Segment design that keeps a fault contained rather than taking a ward offline
- Documented handover pack and logbook aligned to UK O&M expectations
Documentation
Documents open on the manufacturer’s site so you always get the current revision.
